Features & Benefits

TWO DRIVE SYSTEMS AVAILABLE
A new valve operated drive that has reduced electrical demands and has more operational versatility.  Also our time proven standard drive that reverses the drive motor.

FAST STITCHING CYCLE
Coils are fastened in 4 to 15 seconds depending on model, power supply and die opening ( 2 3/4" (70 mm) standard or 4" (102 mm) option). Some larger joiners for heavy materials will have slightly longer cycle times.

WIDE RANGE OF MATERIAL THICKNESS WITH ONE MACHINE
Adjustable Depth Switch limits depth of penetration for various metal thicknesses ranging from 0.004" (0.1mm) to 0.313" (8mm)

IMPERIAL OR METRIC FASTENERS
Imperial fasteners is our standard, however, as a no cost option we will build your joiner with metric fasteners where it is possible. A few exclusive parts will still have imperial fasteners.

SELF-CONTAINED UNIT
The joiner comes complete with motor (drip proof or TEFC), reservoir, pumps, cylinders, controls and joining dies. No external hydraulic supply needed. Just anchor to floor and provide with electric power and shop air for valve drive.

COMPACT UNIT FITS EASILY INTO EXISTING LINES
Narrow width generally allows installation without rearranging existing line.

LONG LIFE DIE
Dies are precision machined with no internal moving parts.

NO CONTAMINATION BY FOREIGN MATERIALS
Stitch utilizes only the metal in your coil. Stitch section can easily be reprocessed.

LOCAL OR REMOTE OPERATION
Local two push buttons complete the stitching operation. Remote operation is by PLC interface control. The RAM is automatically reversed through RAM position sensing.

DURABLE INDUSTRIAL FINISH
Customer specifies the color(s). Allows for integration within current facility and safety code compliance.

EASY DIE REMOVAL
Die can be removed from either side or either end of the press. Quick die change kits are available to reduce change over time.

SIMPLE MAINTENANCE
Designed to give years of trouble-free service. The design of the strip joiner contains the best combination of function and reliability.

HIGH STRENGTH STITCH JOINT
No matter the thickness of material, a solid, durable stitch is made.

DESIGN INTEGRATION
Starter panel allows for integration into the process line controls.

OPTIONS
Splice detection hole punch, guide rollers, entry guides, exit tables, doors with safety interlock, slug chute and container, remote control, material clamps, lubrication system, air blow off system and die change

Why Behlen?

Behlen technicians are available to provide after-market service. Our focus is to ensure that our customers are cared for long after the Behlen strip joiner has been installed and running.

Behlen customer service will:

  • Facilitate immediate response to service, maintenance and warranty issues.
  • Handle customer feedback
  • On-site technical assistance is available

In addition to after-market service, Behlen can provide on-site start up service and training at your request.

  • A Behlen service technician will inspect your strip joiner installation to make sure it is properly installed and setup.
  • Next, the service technician can perform startup to make sure your machine is running to design specifications.
  • Finally, the service technician can provide training for your operators and maintenance personnel in proper operation and maintenance of a Behlen strip joiner.
